Description

Sliding Table Saw, 10’6″ New SCM Model #SI400Nova Heavy Duty Sliding Table Saw machine, 9HP Main Motor, 1HP Scoring Motor, 10’6″ Capacity, 230 volt, 3-phase machine. Standard Features Anodized aluminum sliding table with hardened steel guides Self Braking Motor Separate 1 hp scoring motor Tilting arbor from 0 to 45 degrees Mechanical tilt indicator External scoring saw adjustment with stops Slider locks anywhere to the right of the blade Overhead mounted blade guard with dust outlet Heavy industrial aluminum extrusion crosscut fence with flip stops “EZ Dial” Adjustable split scoring blade assembly Standard 1 year warranty (10 years on table guideway tolerances) Separate hand wheels on front for lifting and tilt of blade Eccentric Clamp Electrical control panel tilted 25 deg. for ergonomics Specifications Main Motor Horsepower9 HPScoring Motor Horsepower1 HPFixed Table Size41″ x 25″Height of Worktable34.5″Rip Capacity51″Max Length of Crosscut with Scoring126″Main Blade Diameter / Arbor16″ / 1″Scoring Blade Diameter / Arbor5″ / 3/4″Arbor Speed – main / scoring4,000 / 8,500 RPMDust Outlets – main / overarm guard5″ / 3.25″Depth of Cut – 0° / 45°5.5″ / 3.8″Net Weight2,200 lbsElectrical Requirements36 AMPS @ 230v, 3 phDust Extraction1100 CFM
