Description

Machine Standard Features: Rubber coated pressing rollers before and after sanding unit Additional flexible hold-down plate before sanding unit. .7 HP 2 speed feed unit. Feed speeds set at 15 and 30 feet per minute Electronic digital thickness readout of work table position Electronic positioning of the work table  Powered table lifting by means of four heavy duty motor and lifting columns double fastened at both top and bottom of the lifting columns to provide exceptional table stability  Accurate and reliable electronic tracking of abrasive belt  Pneumatic belt tensioning with center fulcrum to compensate for tapering of abrasive belt  Front and rear emergency stop buttons Automatic emergency stop of machine for sanding belt breaking, tensioning, over tracking opening of the access door to the operating groups  absence of compressed air overload on main motors Amperage meter for main motors allows maximum utilization of available horsepower Main disconnect switch with the ability to be locked out by padlock  50 shore, negative profile (waffle style) rubber feed mat Infeed and Outfeed tables with 2 rollers each Automatic table thickness device  1st Working Unit Working Unit Type: Combination Head: Motor Hp: 18 HP Motor Type: Single Speed Abrasive Belt Speed: 18 mps Drum Size: 120 mm (4.75”) Drum Type: 85 Sh Rubber Platen Size: 50 mm (2”) Platens Included: Two Abrasive Belt Length: 60”
